HD Image Quality and Detail
A high-resolution megapixel sensor provides 720p HD resolution to ensure that you capture the details you need
All-Day Surveillance
A built-in ICR filter and IR illuminator let you monitor an area 24 hours a day, Detect movement even in complete darkness with the onboard PIR
mydlink-enabled Cloud Access
Easy remote viewing and management of your camera on your mobile device or through the mydlink website
The DCS-2132L HD Wireless N Cube Cloud Camera is a mydlink-enabled IP surveillance camera that lets you monitor an area 24 hours a day. It helps you keep an eye on your home or office, even when you’re away.
24/7 HD Surveillance for Your Home or Office
The DCS-2132L is built with a megapixel image sensor to give you high-quality snapshots and video with resolutions up to 720p HD. This gives you sharp, highresolution snapshots and videos with rich detail. Get a closer look with ePTZ, which lets you zoom in, zoom out, and pan across your camera’s video so you can survey a large area easily.
An infrared cut removable (ICR) filter is also built into the DCS-2132L, which blocks infrared light during the day for improved image quality. At night, it moves out of the way to use all available light for low-light surveillance, and paired with the IR LED illuminator, this camera can monitor an area even in complete darkness.
Anywhere Access with mydlink
The HD Wireless N Cube Network Camera is mydlink-enabled, which means that you can access and configure your camera remotely, no matter where you are. See your camera’s live view through the mydlink website, or download the mydlink mobile app and view your camera directly on your iOS or Android mobile device. Keep an eye on your home while you’re at work, or check on the office when you’re out on the road; mydlink makes it all possible.
Zero Configuration
If you have a mydlink-enabled Cloud Router, setting up and configuring your DCS-2132L is a snap, thanks to mydlink Zero Configuration. Simply connect your camera to its power adapter and then connect your camera to your Cloud Router with an Ethernet cable - the camera will automatically be added to your account. mydlink does the hard work for you, allowing users to set up and use their Cloud-enabled cameras immediately.
Built for Versatility
The DCS-2132L comes with a wealth of features that enhance its surveillance capabilities, making it ideal for any situation. A passive infrared (PIR) sensor detects motion near the camera, allowing it to automatically record video and send you a notification when motion is detected. A built-in microphone and speaker allow for 2-way communication, which is ideal for use in entryways or for caretaker applications. It even includes 802.11n wireless connectivity, allowing it to be placed anywhere easily without requiring cabling to be installed.
A Complete, Expandable Surveillance Solution
The DCS-2132L is a self-sufficient surveillance solution, capable of recording snapshots and video to a MicroSD card without requiring a PC or network storage device.
If you want to expand your surveillance options, D-ViewCam management software is also included, giving you the ability to manage up to 32 cameras with a robust set of features, including multi-camera views and automated e-mail alerts to keep you informed of suspicious or unusual activities
D-Link DCS-2132L. Tipo: Telecamera di sicurezza IP, Posizionamento supportato: Interno, Tecnologia di connessione: Con cavo e senza cavo. Fattore di forma: Scatola, Tipo di montaggio: Scrivania, Colore del prodotto: Bianco. Angolo di visualizzazione (orizzontale): 57,8°, Angolo di visualizzazione (verticale): 37,8°. Tipo sensore: CMOS, Dimensioni sensore ottico: 25,4 / 4 mm (1 / 4"). Zoom digitale: 10x, Range di focus normale: 0.3 m, Lunghezza focale fissa: 3,45 mm
| Prestazione |
| Tipo | Telecamera di sicurezza IP |
| Posizionamento supportato | Interno |
| Tecnologia di connessione | Con cavo e senza cavo |
| Controllo PTZ | Sì |
| Certificazione | CE, CE LVD, FCC, ICES, C-Tick |
| Design |
| Fattore di forma | Scatola |
| Tipo di montaggio | Scrivania |
| Colore del prodotto | Bianco |
| Indicatori LED | Potenza |
| Macchina fotografica |
| Angolo di visualizzazione (orizzontale) | 57,8° |
| Angolo di visualizzazione (verticale) | 37,8° |
| Sensore d'immagine |
| Tipo sensore | CMOS |
| Dimensioni sensore ottico | 25,4 / 4 mm (1 / 4") |
| Sistema di lente |
| Zoom fotocamera | Sì |
| Zoom digitale | 10x |
| Lunghezza focale fissa | 3,45 mm |
| Veduta notturna |
| Visione notturna | No |
| Video |
| Risoluzione massima | 1280 x 800 Pixel |
| Megapixel totali | 1 MP |
| Formati video supportati | H.264,MPEG4 |
| Risoluzioni grafiche supportate | 1024 x 768 (XGA),1280 x 720 (HD 720),1280 x 800 (WXGA),640 x 480 (VGA),800 x 600 (SVGA) |
| Modalità video supportate | 720p |
| Frame rate | 30 fps |
| Audio |
| Sistema audio | 2-vie |
| Microfono incorporato | Sì |
| Collegamento in rete |
| Collegamento ethernet LAN | Sì |
| Wi-Fi | Sì |
| Protocolli di rete supportati | IPv6, IPv4, TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP / HTTPS, Samba client, PPPoE, UPnP, RTP/RTSP/RTCP, IP filtering, QoS, CoS, Multicast, IGMP, ONVIF |
| Standard Wi-Fi | Wi-Fi 4 (802.11n) |
| Tecnologia di cablaggio | 10/100 BASE-T(X) |
| Archiviazione |
| Disco rigido integrato | No |
| Lettore di schede integrato | Sì |
| Tipi schede di memoria | MicroSD (TransFlash) |
| Connettività |
| Quantità porte Ethernet LAN (RJ-45) | 1 |
| Uscite per cuffie | 1 |
| Jack DC-in | Sì |
| Interfaccia | RJ-45 |
| Sicurezza |
| Protezione password | Sì |
| Crittografia HTTPS | Sì |
| Gestione energetica |
| Frequenza di ingresso AC | 50 - 60 Hz |
| Consumi | 3,65 W |
| Ampère CC in uscita | 1,2 A |
| Supporto Power over Ethernet (PoE) | No |
| Condizioni ambientali |
| Intervallo temperatura di funzionamento | 0 - 40 °C |
| Intervallo di temperatura | -20 - 70 °C |
| Range di umidità di funzionamento | 20 - 80% |
| Umidità | 5 - 95% |
| Requisiti di sistema |
| Sistema operativo Windows supportato | Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 |
| Dimensioni e peso |
| Larghezza | 58 mm |
| Profondità | 30,7 mm |
| Altezza | 95 mm |
| Peso | 116 g |
| Contenuto dell'imballo |
| Manuale dell'utente | Sì |
| Adattatore AC/DC | Sì |
| Guida rapida | Sì |
