Zyxel ATP100. Throughput firewall: 1000 Mbit/s, Velocità massima di trasferimento dati: 1000 Mbit/s, Throughput VPN: 300 Mbit/s. Dissipazione del calore: 42,65 BTU/h, Utenti correnti: 10 utente(i), Tempo medio tra guasti (MTBF): 989810,8 h. Algoritmi di sicurezza supportati: IPSec, SSL/TLS, Supporto VPN: IKEv2, IPSec, SSL, L2TP/IPSec. Tecnologia di connessione: Cablato, Velocità trasferimento Ethernet LAN: 10,100,1000 Mbit/s, Console port: RJ-45. Corrente d'ingresso: 2 A, Consumi: 12,5 W, Consumo energetico (max): 12,5 W
| Trasmissione dati |
| Velocità massima di trasferimento dati | 1000 Mbit/s |
| Throughput firewall | 1000 Mbit/s |
| Throughput VPN | 300 Mbit/s |
| Throughput VPN IPSec | 40 Gbit/s |
| Performance SSL | 10 transazioni/s |
| Connessioni massime (SPI) | 1000 |
| Crittografia HTTPS | Sì |
| Prestazione |
| Dissipazione del calore | 42,65 BTU/h |
| Utenti correnti | 10 utente(i) |
| Tempo medio tra guasti (MTBF) | 989810,8 h |
| Certificazione | FCC Part 15 (Class B), CE (Class B), RCM (Class B), BSMI, LVD |
| Collegamento in rete |
| Quantità tunnerl VPN | 40 |
| Connessioni TCP attive (max) | 300000 |
| Sicurezza |
| Algoritmi di sicurezza supportati | IPSec, SSL/TLS |
| Filtraggio stateful dei pacchetti (SPI) | Sì |
| Filtro contenuti | 1 |
| Supporto VPN | IKEv2, IPSec, SSL, L2TP/IPSec |
| Connettività |
| Tecnologia di connessione | Cablato |
| Quantità di porte USB 3.2 Gen 1 (3.1 Gen 1) di tipo A | 1 |
| Quantità porte Ethernet LAN (RJ-45) | 4 |
| Console port | RJ-45 |
| Numero di porte della console | 1 |
| Quantità di slot per modulo SFP | 1 |
| Design |
| Ventola integrata | Sì |
| Gestione energetica |
| Corrente d'ingresso | 2 A |
| Consumo energetico (max) | 12,5 W |
| Condizioni ambientali |
| Intervallo temperatura di funzionamento | 0 - 40 °C |
| Intervallo di temperatura | -30 - 70 °C |
| Range di umidità di funzionamento | 10 - 90% |
| Umidità | 10 - 90% |
| Dimensioni e peso |
| Dimensioni (LxPxA) | 216 x 143 x 33 mm |
| Peso | 850 g |
| Dati su imballaggio |
| Larghezza imballo | 284 mm |
| Altezza imballo | 190 mm |
| Profondità imballo | 100 mm |
| Peso dell'imballo | 1,4 kg |
| Contenuto dell'imballo |
| Cavi inclusi | LAN (RJ-45), RS-232 |
